P-Channel Power MOSFET- IRF9540

Part ID: VT-1693
  • Sale
  • Regular price 3 QAR

IRF9540N is new generation of high voltage MOSFET family that is utilizing an advanced charge balance mechanism for outstanding low on-resistance and lower gate charge performance. This advanced technology has been tailored to minimize conduction loss, provide superior switching performance, and withstand extreme dv/dt rate and higher avalanche energy. It is very suitable for various AC/DC power conversion in switching mode operation for system miniaturization and higher efficiency.

  • Number of Channels: 1 Channel
  • Transistor Polarity: P-Channel
  • Drain-Source Breakdown Voltage (Vds): -100V
  • Continuous Drain Current (Id): -23A
  • Drain-Source Resistance (Rds On): 0.117Ohms
  • Gate-Source Voltage (Vgs): 20V
  • Gate Charge (Qg): 97 nC
  • Operating Temperature Range: -55 - 175°C
  • Power Dissipation (Pd): 140W
