Non-invasive Current Sensor - 30A

  • Sale
  • Regular price 39 QAR
  • Product ID: VT-1368
    6 in stock

  • This is SCT 013 30A Non-Invasive AC Current Sensor Split Core Type Clamp Meter Sensor. SCT-013- is a Non-Invasive AC current sensor i.e. it is a current transformer which can be used to measure AC current up to 30 amperes.

    Current transformers (CTs) are sensors are for measuring alternating current. They are particularly useful for measuring whole building electricity consumption (or generation for that matter). The split core type such as the SCT-013- CT in the picture is particularly suitable for DIY use. Clip this SCT 013  straight on to either the live or neutral wire coming into the building without having to do any high voltage electrical work.

    Like any other transformer, a current transformer has a primary winding, a magnetic core, and a secondary winding. In the case of whole building monitoring the primary is the life or the neutral wire (not both) coming into the building itself and goes through the hole in the CT. The secondary winding comprises many turns of fine wire housed within the casing of the transformer.

    • Current input to voltage output relation: 30A 1V
    • Reference project: Open Energy Monitor
    • Core Material: Ferrite
    • Dielectric Strength:6000V AC/1min
    • Anti-flaming rate:UL94-V0
    • Mechanical strength: opening and closing times, no less than 1000 times (20
    • Celsius)
    • Opening Size: Approx. 0.51 x 0.51inch / 13 x 13mm
    • Dielectric Strength:6000V AC/1min
    • Working Temperature:-25-70 Celsius
    • Cable Length: Approx. 41.37 inch / 105cm
