Miniature Slip Ring - 4 Channel

  • Sale
  • Regular price 49 QAR
  • Product ID: VT-4052
    2 in stock

    With a slip ring assembly, your electronics can now twist and turn safely. Add wheel encoders, 360 degree sensors, rotating LEDs, rotors and more! We've seen a lot of people DIY slip ring's out of desperation but no longer, simply pick up one of these to solve any rotation needs you have.

    • Max Rotating Speed:  250 rpm
    • Channel number: 4 Channel
    • Rated voltage: 240VAC/DC
    • Rated current: 2a /channel
    • Operating temperature: -40 to +80
    • Contact material: Gold
    • Cable Size: AWG30 Silver-plated Teflon UL
    • Cable length: 200mm
    • Compressive strength: between the two channels>=500V 50Hz
    • Insulation resistance: 1000MOhm/500VDC
    • Working life:>=10 million rpm(depending on the working environment and speed)
