Raspberry Pi Zero Single-Board Computer – Ultra-Compact Design

The Raspberry Pi Zero is a compact single-board computer designed for embedded systems, education, and space-constrained applications. It is powered by a single-core 1 GHz ARM processor and features 512 MB LPDDR2 memory for lightweight computing tasks. The board provides Mini HDMI video output, Micro USB interfaces for power and data, and a microSD card slot for operating system storage. Built for reliable operation, it supports standard Raspberry Pi OS and Linux distributions. Its unpopulated 40-pin GPIO header and CSI camera connector enable flexible hardware integration. Suitable for IoT devices, learning projects, and custom embedded designs.

• Broadcom BCM2835 SoC – 1GHz single-core processor
• 512MB RAM – Efficient for lightweight computing tasks
• Single-Core Processing – Optimized for low-power workloads
• VideoCore IV Multimedia Engine – Video and image processing acceleration
• OpenGL ES 2.0 Support – Basic graphics rendering capability

• Bare Board Design – No pre-soldered headers

• Test Pads for GPIO Access – Alternative hardware connections

• CSI Ribbon Interface – Dedicated camera interface
• No Onboard Networking – External USB adapters required

• No Onboard Bluetooth – Wireless via USB modules

• Lightweight Linux Distributions – Optimized OS compatibility

• Boot via microSD Card – Standard Raspberry Pi boot process

• USB Peripheral Mode – Device emulation capability

• Minimal Heat Output – Passive cooling sufficient

• Educational Hardware Platform – Suitable for electronics learning

• Embedded System Integration – Designed for custom hardware projects

• Operating Voltage: 5 V DC
• CPU Architecture: ARMv6 single-core architecture
• Graphics Processor: Broadcom VideoCore IV
• Graphics API Support: OpenGL ES 2.0
• Video Decoder: H.264 1080p30 hardware decoding
• USB Interface: USB 2.0 OTG
• Boot Mode: microSD card boot
• Camera Interface: MIPI CSI-2
• Audio Output: HDMI audio output
• GPIO Voltage Level: 3.3 V logic
• Header Type: Unpopulated pin header
• Cooling Method: Passive cooling
• Operating Temperature: 0 to 50 °C
• Power Consumption: Low-power embedded operation
• Supported Platforms: Raspberry Pi OS, Linux
