74279 Quad Set-Reset Latch Logic IC

The 74279 is a TTL logic IC that integrates four independent set-reset latches in a single package.
It provides asynchronous data storage using separate set and reset control inputs.
The device operates from a single 5 V supply and is compatible with standard TTL logic levels.
Each latch maintains its output state until an opposing control input is asserted.
Typical applications include state storage, control logic, signal debouncing, and digital sequencing circuits.

• Quad SR Latch Configuration providing four independent latches

• Asynchronous Set and Reset Inputs for immediate state control

• TTL Logic Family compatible with standard TTL levels

• Independent Outputs enabling flexible logic design

• Stable State Retention until control input change

• Through-Hole DIP Package for breadboard and PCB use

• Model | 74279

• Device Type | Quad Set-Reset Latch IC

• Logic Family | TTL

• Number of Latches | 4

• Control Inputs | Set and Reset

• Supply Voltage | 5 V

• Input Logic Levels | TTL Compatible

• Propagation Delay (Typical) | 20 ns

• Power Consumption (Typical) | 15 mW per latch

• Operating Temperature Range | 0 °C to 70 °C

• Package Type | 16-Pin DIP

• 3D Model
• Datasheet
