60mm Dome Illuminated Push Button – 12V LED Microswitch

The 60mm Dome Illuminated Push Button is a large-format control switch designed for arcade systems, control panels, and interactive installations. It features an integrated 12V LED indicator and a pre-installed horizontal microswitch for reliable switching performance. The polycarbonate dome ensures high optical clarity and durability, while the adjustable design allows conversion to a low-profile button. Built for long-term use, the microswitch is rated for up to 10 million cycles and can be easily replaced. Ideal for arcade machines, DIY electronics, kiosks, and industrial control interfaces.

• 60mm dome button design for high visibility

• Integrated 12V DC LED illumination

• Pre-installed horizontal microswitch included

• Microswitch rated for 10,000,000 cycles

• 3-terminal actuator for flexible wiring

• Replaceable microswitch design

• Adjustable height with removable middle ring

• Polycarbonate lens for high optical clarity

• Durable construction for frequent use

• Easy installation with mounting nut

• Suitable for arcade and control panel applications

• Stable switching performance under repeated use

• Compatible with low-voltage DC systems

• Secure mounting with standard panel cutout


• Operating Voltage (LED): 12V DC

• Switch Type: Microswitch (SPDT, 3 terminals)

• Button Diameter: 60 mm

• Height: 72 mm

• Mounting Hole Diameter: 24 mm

• Material: Polycarbonate lens and plastic body

• Switch Life Cycle: 10,000,000 operations

• Illumination Type: LED

• Contact Configuration: NO/NC/COM

• Weight: 100 g

• Actuator Type: Dome push button

• Installation Method: Panel mount with locking nut

• Adjustable Profile: Yes (removable middle ring)

• Assembling Experience Lights Big LED Buttons
