TB6600 Stepper Motor Driver Module – 4A 9–42V Microstepping

The TB6600 stepper motor driver module is designed for precise control of bipolar stepper motors in CNC and automation systems. It operates within a 9–42V DC input range and supports up to 4A output current with selectable current levels. The driver features multiple microstepping modes up to 1/32 step resolution, enabling smooth and accurate motion control. Built with optical isolation for high-speed input signals, it ensures reliable performance and noise immunity. Ideal for CNC machines, 3D printers, and industrial motion control applications.

• TB6600 driver chipset for bipolar stepper motor control

• 9–42V DC wide input voltage range

• Adjustable output current up to 4A

• 8 selectable current levels

• Microstepping modes up to 1/32 step resolution

• High-speed optocoupler isolated input signals

• Standard common anode pulse interface

• Offline hold function for energy saving

• Semi-enclosed housing for improved durability

• Automatic semi-flow current reduction

• Built-in thermal protection circuit

• Overcurrent protection mechanism

• Stable operation with low noise output

• Compatible with CNC controllers and microcontrollers


• Input Voltage: 9–42V DC

• Output Current: 0.5–4.0A (adjustable)

• Number of Current Levels: 8 levels

• Microstepping Modes: Full, 1/2, 1/4, 1/8, 1/16, 1/32

• Control Signal: Pulse + Direction

• Input Signal Type: Optically isolated

• Logic Signal Voltage: 3.3–24V DC

• Max Pulse Frequency: 20 kHz

• Motor Type: Bipolar stepper motor

• Protection Features: Thermal, overcurrent

• Cooling Method: Passive + heatsink

• Operating Temperature: -10°C to 45°C

• Storage Temperature: -20°C to 65°C

• Module Dimensions: 96 × 56 × 33 mm

• Weight: 150 g
